Product Specification
Unit | VMC320 | VMC420E | Mega Y VMC400 | VMC600E | VMC500 | Mega Z VMC850 | VMC1050E | ||
Table | Table size | mm | 600x305 | 720x305 | 600x380 | 800x380 | 700x400 | 1200x520 | 1300x520 |
T slot(width*nos.*distance) | mm | 14x3x85 | 14x3x305 | 14x3x110 | 14x3x110 | 18x3x110 | 18x5x90 | 18x5x90 | |
Max.load | kg | 260 | 260 | 350 | 350 | 350 | 750 | 750 | |
Travel | X/Y/Z Travel | mm | 320/240/450 | 420/240/450 | 400/350/450 | 600/350/450 | 500/400/450 | 850/500/600 | 1050x500x600 |
Spindle nose to table | mm | 50-500 | 50-500 | 50-500 | 50-500 | 90-540 | 130-700 | 130-700 | |
Spindle center to column | mm | 380 | 380 | 450 | 450 | 450 | 580 | 580 | |
Guideway type | LM:XYZ | LM:XYZ | LM:XYZ | LM:XYZ | LM:XYZ | LM:XYZ | LM:XYZ | ||
Spindle | Spindle type | BT30 | BT30 | BT40 | BT40 | BT40 | BT40 | BT40 | |
Main servo motor | kw | 3.7/5.5 | 3.7/5.5 | 3.7/5.5,*5.5/7.5 | 3.7/5.5,*5.5/7.5 | 5.5/7.5,*7.5/11 | 7.5/11.0 | 7.5/11.0 | |
Spindle speed | rpm | 6000,*8000 | 6000,*8000 | 6000,*8000,*12000 | 6000,*8000,*12000 | 8000,*12000 | 8000,*12000 | 8000,*12000 | |
Feed&Magazine | X/Y/Z axis rapid traverse | m/min | 20/20/20 | 20/20/20 | 20/20/20 | 20/20/20 | 20/20/20 | 30/30/30 | 30/30/30 |
RTC capacity/type | No./tpey | 12/Drum | 12/Drum | 16/drum,*20/Arm | 16/drum,*20/Arm | 16/drum,*24/Arm | 24/Arm | 24/Arm | |
Max.weight of tool | kg | 3 | 3 | 8 | 8 | 8 | 8 | 8 | |
Dimension&Weight | Power capacity | KVA | 14 | 14 | 15 | 15 | 17 | 21 | 21 |
Dimension | mm | 2080x1900x2300 | 2080x1900x2300 | 2400x2000x2320 | 2400x2000x2320 | 2300x2100x2200 | 3000x2200x2350 | 3000x2200x2350 | |
Weight(about) | kg | 2000 | 2000 | 2400 | 2500 | 2900 | 6500 | 6800 |
