Product Specification
Unit | FL400 | FL500 | FL550 | FL630 | ||||||
Capacity | Chuck/collet | tyoe | Manual chuck 8" | Manual chuck 10" | Manual chuck 12" | Manual chuck 15" | ||||
*Hydraulic chuck 8",6" | *Hydraulic chuck 10",8" | *Hydraulic chuck 12" | *Hydraulic chuck 15" | |||||||
Bed type/guideway | Flat/LM | Flat/LM | Flat/LM | Flat/LM | ||||||
Max.swing dia.over bed | mm | Ø400 | ø500 | ø500 | ø650 | |||||
Max,length of workpiece | mm | 320 | 500 | 500 | 450 | |||||
Max.swing dia.over slide | mm | Ø180 | ø360 | ø360 | ø380 | |||||
Spindle | Spindle bore | mm | ø62 | ø48 | ø81 | *ø62 | ø105 | ø120 | ||
Max.dia.of through hole | mm | ø52 | ø40 | ø70 | *ø52 | ø91 | ø110 | |||
Spindle nose | A2-6 | A2-5 | A2-8 | *A2-6 | A2-11 | A2-11 | ||||
Spindle speed | rpm | 2000*3500 | 3000*4500 | 1600 | *2000 | 1000 | 1000 | |||
*2500 | *3500 | *1800 | ||||||||
*4000 | ||||||||||
Spindle motor power | kw | 5.5/7.5 | 5.5/7.5,*7.5/11 | 7.5/11,*11/15 | 11/15,*51/18.5 | |||||
Axis | X/Z travel | mm | 380/350 | 260/500,*350/500 | 260/500,*350/500 | 350/500 | ||||
X/Z rapid traverse | m/min | 20/20 | 12./9 | 12./9 | 20/20 | |||||
Tool post | Type | 4-station toolpost | 4-station toolpost | 4-station toolpost | 4-station toolpost | |||||
*8-station turret | *8-station turret | *8-station turret | *8-station turret | |||||||
*Gang type tooling | *Gang type tooling | *Gang type tooling | *Gang type tooling | |||||||
No.of tool stations | No. | 4~10 | 4~10 | 4~10 | 4~10 | |||||
Others | Power capacity | KVA | 11 | 12 | 12 | 18 | ||||
Dimensions(LxWxH) | mm | 1950x1250x1620 | 2650x1360x1800 | 2650x1360x1800 | 2650x1360x1800 | |||||
Weight(about) | kg | 2000 | 2700 | 2800 | 3000 |
